FUMASEP® ION EXCHANGE MEMBRANES

HOMOGENOUS AND HETEROGENEOUS MEMBRANES FOR ELECTROCHEMICAL PROCESSES

FUMASEP® FAS AND FKS are standard homogeneous anion and cation exchange membranes. Optimized in terms of conductivity, area resistance, perm selectivity and membrane thickness for use in electrodialysis (ED) systems.

FUMASEP® FAB is an anion exchange membrane which is designed for very low proton crossover to achieve high concentrations of acid.

FUMASEP® FKB is a cation exchange membrane optimized for high cation transport in combination with high OH-retention.

FUMASEP® FAB, FKB are designed and optimized for electrodialysis with bipolar membranes (EDBM).

FUMASEP® FAD anion exchange membrane is characterized by permeability for acids and high rejection rate for metal ions.

FUMASEP® FKD cation exchange membrane is used for application of diffusion dialysis for spent caustic. Up to 95 % of free acid and up to 80 % of the free base can be recovered and recirculated to the production process. This results in important savings and significant reduction of chemical consumption in industrial processes.

FUMASEP® FKL is a cation exchange membrane for concentration of caustic by electrodialysis.

Elektrodialyse
Elektrodialyse

Physical and chemical properties

Desig­na­tion Type Rein­force­ment Thick­ness Area resis­tance Selec­tivity Stability
      µm Ωcm²  % pH

Stan­dard Grade Membranes for Elec­tro­dial­ysis
FAS Anion PES / PK 75 / 130 2.5 - 3.5 92 - 97 1-9 / 1-14
FKS Cation PES / PK 75 / 130 2.0 - 4.0 > 96 1-9 / 1-14

Special Grade Membranes for Elec­tro­dial­ysis with Bipolar Membranes
FAB Anion PK 75 / 130 5.0 - 7.5 > 92 1-14
FKB Cation PK 75 / 130 2.5 - 5.0 > 97 1-14

Special Grade Membranes
FAD Anion PES 75 < 1.2 > 85 1-9
FKD Cation PK 75 < 2.0 > 89 1-14
FKL Cation PK 75 / 130 6.0 - 10.0 > 98 1-14

Membranes for Elec­trodeion­iza­tion
FAM Anion PP Fabric 450 - 600 12 - 25 > 92 1-9
FKM Cation PP Fabric 450 - 600 12 - 25 > 95 1-9
